C-Band Transceiver Revision 1
CSAT-5060 5 to 25 Watt Installation MN/CSAT5060.IOM
A–9
A.3 SPAR-MOUNT INSTALLATION
A.3.1
Mounting kit
Table A-2 reflects the contents of the mounting kits.
Table A-2. SPAR Mount Installation
Part No. Nomenclature QTY
*KT/9676-1 Kit, SPAR Mounting, 1 x 2 1
*KT/9676-2 Kit, SPAR Mounting, 2.5 x 2.5 1
* Customer-Select
Figure A-10. SPAR-Mount Configuration
