Chapter 3. CONNECTOR PINOUTS
3.1 Pin-outs
3.1.1
Connector J3: AC Power, Mains, 100 to 125 VAC, or
205 to 240 VAC.
WARNING
To avoid a serious shock hazard, correctly determine the mating
connector type in use and wire it according to the following table:
EARLY UNITS NEWER UNITS
Pin Mating Connector Type
KPT06J12-3S
MS3116J12-3S
Mating Connector Type
CA3106E18-22SB
A Line Ground
B Ground Neutral
C or G Neutral Line
Table 3-1. –48VDC Input Option
Pin Description
A Return
B Chassis Ground
C -48 VDC
D No Connection
