CSAT-5060 C-Band Transceiver Revision 1
Ethernet-based Remote Product Management MN/CSAT5060.IOM
AA–2
AA.2 Ethernet Management Interface Protocols
The PC gives you access to Ethernet-based remote monitor and control (M&C) of the unit. There
are two, separately-operated protocols available:
• Simple Network Management Protocol (SNMP). This non-secure interface requires a
user-supplied Network Management System (NMS) and a user-supplied Management
Information Base (MIB) File Browser.
• Telnet Interface. This non-secure interface uses the PC’s command-line interface, or a
user-supplied terminal emulation program such as HyperTerminal.
AA.3 SNMP Interface
The Simple Network Management Protocol (SNMP) is an Internet-standard protocol for
managing devices on IP networks. An SNMP-managed network has these key components:
• The managed device. This includes the CSAT-5060 unit.
• The SNMP Agent. This is the software that runs on the unit. The SNMP Agent supports
both SNMPv1 and SNMPv2c.
• The user-supplied Network Management System (NMS). This is the software that runs
on the manager.
AA.3.1 Management Information Base (MIB) Files
These MIB files are used with the CSAT-5060:
MIB File/Name
(where ‘x’ is
Description
FW-0020546x.mib
ComtechEFData Root
MIB file
ComtechEFData MIB file gives the root tree for ALL Comtech EF Data CSAT-5060
products and consists of only the following OID:
Name: comtechEFData
Type: MODULE-IDENTITY
OID: 1.3.6.1.4.1.6247
Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtechEFData(6247)
Module: ComtechEFData
FW-0020599x.mib
csat-5060 MIB file
MIB file consists of all of the OIDs for management of the CSAT-5060 functions
FW-0020600x.mib
csat-5060 Traps MIB
file
Trap MIB file is provided for SNMPv1 traps common for CSAT-5060.
An MIB file is used for SNMP remote management of a unique device, and consists of a tree of
nodes called Object Identifiers (OIDs). Each OID permits remote management of a particular
function.
