CSAT-5060 C-Band Transceivers Revision 1
Appendix A MN/CSAT5060.IOM
A–21
CSAT Remote Commands
Parameter
Type Command Arguments Description of arguments
Response to
Command Query
Response to
Query
Concise Alarm
Status
N/A
19 bytes,
numerical
Query only.
Used to Query the Alarm status of the CSAT
Example: CMS=abcdefghijklmnopqr’cr’’lf’
where: a thru n = 0 or 1, 0 = OK 1 = FT
a = 24V Power Supply Alarm
b = 20V Power Supply Alarm
c = 12V Power Supply Alarm
d = 10V Power Supply Alarm
e = +5V Power Supply Alarm
f = -5V Power Supply Alarm
g = TX Synthesizer Lock Detect Alarm
h = TX IFLO Lock Detect Alarm
I = RX Synthesizer Lock Detect Alarm
j = RX IFLO Lock Detect Alarm
k = Reference Lock Detect Alarm
l = LNA Current Alarm
m = Fan Current Alarm
n = Temperature Alarm
o = HPA Thermal Shutdown Alarm
p = Internal IIC-bus Alarm
q = EEPROM checksum Alarm
r = NVRAM/RTC Low Battery Alarm
s = Redundancy switch alarm
N/A CAS? CAS=x….x
See Note 2
Summary Fault
Status
N/A
1 byte,
alpha numerical
Query only.
Used to Query the status of the CSAT Summary
Fault Relay.
Example: SFS=0’cr’’lf’
where: 0 = OK 1 = FT
N/A SFS? SFS=x
See Note 2
Retrieve Firmware
Number for the
M&C board
N/A
6 bytes,
alpha numerical
Query only.
Used to Query M&C board’s firmware number
Example: FRW=FW1516
N/A FRW? FRW=x
See Note 2
