CSAT-5060 C-Band Transceivers Revision 1
Appendix A MN/CSAT5060.IOM
A–20
CSAT Remote Commands
Parameter
Type Command Arguments Description of arguments
Response to
Command Query
Response to
Query
Concise
Maintenance
Status
N/A
80 bytes,
numerical
Query only.
Used to Query the Maintenance status of the CSAT
Example: CMS=aaa.abbb.bccc.cddd.deee.e
fff.fggg.ghhh.hiii.ijjj.jkkk.klll.lmmm.m
nnn.nooo.oppp.p’cr’’lf’
where:
aaa.a = 24V Power Supply
bbb.b = 20V Power Supply
ccc.c = 12V Power Supply
ddd.d = 10V Power Supply
eee.e = +5V Power Supply
fff.f = -5V Power Supply
ggg.g = TX Synthesizer Tuning Voltage
hhh.h = TX IFLO Tuning Voltage
iii.i = RX Synthesizer Tuning Voltage
jjj.j = RX IFLO Tuning Voltage
kkk.k = Reference Tuning Voltage
lll.l = LNA Current in milliamps
mmm.m = Fan Current in milliamps
nnn.n = Up Conv Heat Sink Temperature
ooo.o = RF Output Power in dB
ppp.p = Down Converter Temperature
Note: Value is xxx.x if not available
N/A CMS? CMS=x….x
See Note 2
