A.4.3 CSAT with Ethernet Remote Commands
Command = Instruction Code and Qualifier
Arguments apply to Command or to Response to Query
Response to Command = Target to Controller
These codes are used in the Response to Command column:
= Message ok.
? Received ok, but invalid arguments were found
* Message ok, but not permitted in current mode
Description of Arguments:All arguments are ASCII numeric codes between 48 and 57.
Query = Instruction Code and Qualifier
Response to Query = Target to Controller
Note 1 – Same format as command argument
Note 2 – See Description of arguments for details
CSAT with Ethernet Remote Commands
Parameter
Type
Command Arguments Description of arguments Response to Command Query
Response to
query
Software Image
IMG=
1 byte
Command or Query.
Current Active software image, where:
1=Bulk Image # 1 currently active
2=Bulk Image # 2 currently active
Example: IMG=1 (which is Image #1 active)
IMG=
IMG?
IMG*
IMG#
IMG?
IMG=x
See Note 2
IP Address
IPA=
18 bytes
Command or Query.
Used to set the IP address and network prefix for the
10/100 BaseT Ethernet management port, in the format:
xxx.xxx.xxx.xxx.yy, where:
xxx.xxx.xxx.xxx is the IP address, and
yy is the network prefix (8-30)
Example: 192.168.001.004.24
Default Value: 192.168.001.004.24
IPA=
IPA?
IPA*
IPA#
IPA?
IPA=
xx.xxx.xxx.xxx.yy
See Note 2
Gateway
Address
IPG=
15 bytes
Used to set the Gateway IP address for the
10/100 Base Tx Ethernet management port, in the
format:
xxx.xxx.xxx.xxx, where:
xxx.xxx.xxx.xxx is the IP address
Example: IPG = 192.168.001.005
Default Value: 192.168.001.005
IPG= (message ok)
IPG? (received ok, but
invalid arguments found)
IPG * (message ok, but
not permitted in current
mode
IPG?
IPG =
xxx.xxx.xxx.xxx
