C-Band Transceiver Revision 1
Specification MN/CSAT5060.IOM
2-8
Conversion
Monitor & Control
Conversion Dual, no spectral inversion Methods Both RS-485 and RS-232 Serial Interface
Handheld controller, optional
Frequency
Step Size
1.0 and 2.5 MHz automatic Commands Set TX/RX frequency
Set TX/RX attenuation
Report TX output power
Mute TX
Report internal temperature
Report power supply voltages
Set Time/Date
Frequency
Stability
1 x 10
-9
/day
1 x 10
-7
/year
40° to +55°C
(-40 to 131°F)
1 x 10
-8
/Temperature
Faults Up/Down converter functions
Up/Down converter synthesizers
Internal reference oscillator
LNA current fault
Over temperature condition
Attenuation
TX
RX
0 to 25dB in 0.25db steps
0 to 20dB in 0.25dB steps
Environmental
Temperature
-40 to +55°C (-40 to 131°F) Operating
-50 to +75°C (-58 to 167°F) Storage
Phase
Noise
100 Hz
1 kHz
10 kHz
100 kHz
-66 dBc/Hz
-76 dBc/Hz
-86 dBc/Hz
-96 dBc/Hz
Altitude 15,000ft, mean sea level
Humidity 0 to 100 percent, relative
Prime Power 90 to 260 VAC Standard
47 to 63 Hz Standard
48 VDC Optional
LNA Customer defined
Model:
RF
Power
10dBm 5W 10W 25W 50W 100W 125W
Group
Delay
Linear 0.1 ns/MHz
Parabolic 0.02 ns/MHz
2
Ripple 1 ns p-p
AC
Power
120W 150W 200W 250W 410W 750W 850W
Steady-State True AC Power Requirements (110VAC)
Dimensional
Dimensions
Unit
10dBm, 5W, 10W, 25W
Inches
8H x 8W x 11D
Centimeters
20H x 20W x 28D
50W 9.75H x 10W x 23D 24.77H x 25.4W x 58.42D
100W, 125W 10H x 12.5W x 26D 25.4H x 31.75W x 66.04D
Weight:
Unit
5, 10, 25W
50W
Pounds
36 lbs
65 lbs
Kilograms
16 kg
29 kg
100W, 125W 80 lbs 40 kg
