CSAT-5060 C-Band Transciever Revision 1
+10 dBm Model C-Band Transceiver MN/CSAT5060.IOM
9–5
J8 Connector Pin Out for External Amplifier Communication
+10 dBm CSAT Trasceiver
Pin Number Signal Description
A RX+ (Direct connection to corresponding RS 485pin on J5)
B RX- (Direct connection to corresponding RS 485pin on J5)
C TX+ (Direct connection to corresponding RS 485pin on J5)
D TX- (Direct connection to corresponding RS 485pin on J5)
E No Connect
F Fault (Normally Open), Connection to Pin G will be
interpreted as a fault of the external amplifier
G Fault Common
H Ground
Comtech EF Data Part No. CN/MS3116J12-8P
ITT Cannon Part No. MS3116J12-8P
