C-Band Transceiver Revision 1
CSAT-5060 50 Watt Installation MN/CSAT5060.IOM
B–11
Item No. Part No. Nomenclature QTY
1 FP/BR0066 Bracket, Switch Mounting 1
2 HW/M8FLATSS Washer, Flat M8, SS, Metric 4
3 Not Used
4 HW/M8LOCKSS Washer, Lock SS, Metric 4
5 Not Used
6 HW/M8SPRINGNUT Springnut, M8 X 1.25 4
7 HW/M8X1.25X25HEXSS Bolt, Hex Head, M8 X 1.25 X 25 SS 4
Figure B-9. TX Switch Mounting Kit, AS/0437
