C-Band Transceiver Revision 1
CSAT-5060 100/125 Watt Installation MN/CSAT5060.IOM
C–6
Step Procedures
10 Place assembly on the pole. Slide bracket (3) over bracket (2).
11 Place flat washer (7) and splitlock washer (8), and nut (10) on
bracket (2).
12 Tighten nut to secure the tension strap.
13 Slide two springnuts, (4, figure C-2) into channel of the Unistrut
brackets (1, figure C-1).
14 Repeat procedure for second Unistrut bracket.
15 Install brackets (1, figure C-2) and secure to Unistrut bracket with bolts
(6), flat washers (2) and split lock washers (4).
16 Install four bolts (6), flat washers (2) and splitlock washers (3) on the
CSAT unit.
17 Lift the CSAT unit and slide bolts (6) into the grooves of the
brackets (1). (See Figure C-6.)
18 Ensure the washers are against the bracket.
19 Tighten the bolts.
IMPORTANT
Ensure the brackets are centered in each Unistrut. Ensure the unit
is positioned with the fan facing outward and free of any
obstructions. Do not tighten bolt (5) at this time.
