C-Band Transceiver Revision 1
CSAT-5060 100/125 Watt Installation MN/CSAT5060.IOM
C–19
Step Procedures
CAUTION
DO NOT remove factory-installed waveguide combiner from
outpout of CSAT. Improper installation will damage the unit and
void the warranty.
29
Install the assembled waveguide switch (Figure C-16) and waveguide
gaskets.
30
Secure assembly with bolts, lock washers and flat washers from
hardware kits supplied with each CSAT (not shown, PN AS/0402-2).
Figure C-18. Observe for Gap Figure C-19. Installation of the Waveguide Switch.
Figure C-20. Waveguide layout
