LPOD C- / Ku-Band Outdoor Amplifier/ Block Up Converter (BUC) Revision 3
Appendix B MN-LPOD
B–21
Parameter Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
(Note that all arguments are printable ASCII
characters)
Response to
Command
(Target to Controller)
Query
(Instruction
Code and
qualifier)
Response to
Query
(Target to
Controller)
Unit Alarm Mask MSK= 5 bytes Command or Query.
Alarm mask conditions. If the mask value for a certain
parameter is set to fault then a fault condition will be
registered if specified hardware conditions are not met.
If the mask value is set to alarm then a fault condition
will only appear to be an alarm that will not trigger a
switchover in a redundant system. If the mask value is
set to masked then the fault will never be reported to
the user.
Form of: abcde
Where:
0 = Fault, 1 = Alarm, 2 = Masked
a = Low Forward RF Power
b = External Reference Lock detect
c = Fan Speed
d = LNB Current Detect
e = LNB 22V Power Supply
Example: <1/MSK=22111’cr’
>0001/MSK=1’cr’’lf’
Default Value: 22111
MSK=
MSK?
MSK*
MSK? MSK=abcde
(See Description
of Arguments for
details)
Mute State MUT= 1 byte Command or Query.
Mute the unit, where:
0 = Disable (Not Muted)
1 = Enable (Muted)
2 = Unit muted due to AUX mute signal. This value is
only shown in the response to a query, and cannot be
given as a command. When MUT returns a 2 it
indicates that one of the “hardware” mute conditions is
present. For example an auxiliary mute could be
present if the auxiliary mute has been enabled, and
the signal to unmute the unit is not provided.
Additionally, certain faults can generate a hardware
mute such as the BUC lock detect, the LNB current
draw (if enabled by the user), or the LNB voltage (if
enabled by the user). If MUT returns an unexpected
value of 2 then check the active faults, and the status
of the auxiliary mute.
Example: <1/MUT=1’cr’
>0001/MUT=1’cr’’lf’
Default Value: 1
MUT=
MUT?
MUT*
MUT? MUT=x
(Same format as
command
arguments)
