Comtech EF Data LPOD - Summary of Specifications; Characteristics

LPOD C-/Ku-Band Outdoor Amplifier / Block Up Converter (BUC) Revision 3
Introduction MN-LPOD
1–8
1.5 Summary of Specifications
1.5.1 Characteristics
IF Input Frequency
N
o
t
e
1
RF Output Frequency
950 – 1525 MHz 5.850 – 6.425 GHz
950 – 1750 MHz 5.850 – 6.650 GHz (optional)
950 – 1825 MHz 5.850 – 6.725 GHz (optional)
950 – 1450 MHz 14.00 – 14.50 GHz
950 – 1750 MHz 13.75 – 14.50 GHz (optional)
Model Psat (Typical) P1dB (Guaranteed)
N
o
t
e
2
Gain Min (Typical)
PS-1-20Ku 43 dBm (20W) 42 dBm (16W) 70 (75dB)
PS-1-32Ku 43 dBm (32W) 44 dBm (25W) 70 (75dB)
PS-1-32C 45 dBm (32W) 44 dBm (25W) 70 (75dB)
PS-1-50C 47 dBm (50W) 46 dBm (40W) 70 (75dB)
PS-2-125C 51 dBm (125W) 50 dBm (100W) 70 (75dB)
PS-2-150C 52 dBm (150W) 51 dBm (125W) 70 (75dB)
PS-2-200C 53 dBm (150W) 52.5 dBm (175W) 70 (75dB)
PS-2-250C 54 dBm (250W) 53 dBm (200W) 70 75dB)
Notes:
1. PS-2 Models available as SSPAs only, without internal L-Band BUC (Freq RF in = Freq RF out).
2. Allow 1 dB degradation from 13.75 to 14.0 GHz and 6425 to 6650 MHz.
Input Power Supply Requirements
90-264 VAC, 47-63 Hz, Power Factor Corrected, .96 (typical)
(48 VDC optional)
Model P typical, W P Max, W
PS-1-20Ku 200W 210W
PS-1-32Ku 220W 260W
PS-1-32C 200W 220W
PS-1-50C 270W 300W
PS-2-125C 750W 950W
PS-2-150C 800W 1000W
PS-2-200C 950W 1400W
PS-2-250C 1000W 1500W
Max IF Input level (no damage)
+10 dBm
Gain Adjust
20 dB in 0.25 dB steps
Gain Flatness
± 1.5 dB full band (± 1.0 dB PS-2 configured as SSPA only)
± 0.30 dB per 40 MHz
Gain variation over temp
±1.5 dB max, -40 to +55 °C (±1.25 dB, -40 to +60 °C)
Input Return Loss
15 dB (19.1 dB PS-2 configured as SSPA only)
Output Return Loss
19.1 dB (1.25:1 VSWR)
Noise Figure
10-15 dB typical, 20 dB max @ min. attenuation (8 dB typical,
15 dB max PS-2 configured
RF Mute Isolation
-60 dBc min
