Table A-7. KT-0000091 LPOD PS-2 C-Band 1:1 Redundancy Kit BOM
KT-0000091 LPOD PS-2 C-Band 1:1 Redundancy Kit (as per Figure
A
-8)
ITEM QTY CEFD PART NO. DESCRIPTION
1 1 FP-0000552 WG, C-BAND, CPR-137 G, E TO H TO FLEX, LH, 1:1, PS-2
2 1 FP-0000553 WG, C-BAND, CPR-137 G, E TO H TO FLEX, RH, 1:1, PS-2
3 4 FP-0000442 MOUNTING BRACKET, HPOD-LPOD PS-2
4 2 FP-0000543 CHANNEL, DUAL, UNISTRUT, 1:1 RDNT, LPOD PS-2
5 1 FP-0000626 BRKT, RF SW, UNIVERSAL, 1:1 RED., LPOD PS-2
6 2 FP-0000580 SPACER PLATE, RF SPLITTER / COMBINER
7 1 FP-0000544 BRACKET, MOUNTING, CABLE, MOLDED JUNCTION
11 2 CA/RF0097 ASSY CABLE, ROHS CONNECTOR, CSAT-7075 OUTPUT RF, ROHS
12 1 HW/CAP-SS14 HW DUST COVER,RECEPTACLE,NON-SHORTING,SIZE 14,SS,W/CHAIN & RING
20 1 SW/WGS28V-137S SW WAVEGUIDE, CPR137, +28V SEALED
212 1 FP/WG0034 PNQ, WAVEGUIDE TERMINATION, SMALL FINS
22 1 RF-0000105 RF POWER SPLITTER/COMBINER, 2-WAY, 0 DEGREES, 1-2GHZ
23 4 GA/CPR-137-R-H-C GASKET, D SHAPE, CPR-137, HALF THICKNESS, CONDUCTIVE
24 2 GA/CPR137-R-F-C GASKET, ROUND, CPR137, FULL THICKNESS, CONDUCTIVE
25 12 HW/TW14.5HDBLK CABLE TIE, 14.5", HEAVY DUTY, BLACK
30 10 HW/3/8SPRINGNUT SPRINGNUT, 3/8-16, SHORT SPRING, SST (P3300)
31 10 HW-0000070 SCREW, HEX, FLG, 0.375-16 X 0.750, SST, SERR
33 2 HW/4-40X1.38PH 4-40 X 1/38 P.H. PHIL SCREW SS
34 2 HW/4-SPLIT #4 SPLIT LOCK WASHER SS
35 2 HW/4-FLT #4 FLAT WASHER SS
36 4 HW/6-32X5/16P.H 6-32 X 5/16 PHILLIPS SCREW
37 4 HW/6-SPLIT #6 SPLIT LOCK WASHER SS
38 4 HW/6-FLT #6 FLAT WASHER SS
39 26 HW/10-32X1/2SH 10-32X1/2 SOCKET HEAD CAP SCREW SS
40 30 HW/10-32X5/8SHC 10-32 X 5/8 SOCKET HEAD CAP SCREW SS
41 48 HW/10-SPLIT #10 SPLIT LOCK WASHER SS
42 48 HW/10-FLT #10 FLAT WASHER SS
43 8 HW/5/16-18X3/4B 5/16-18 X 3/4 HEX HEAD BOLT, SS
44 8 HW/5/16-SPLIT 5/16 SPLIT LOCK WASHER
45 8 HW/5/16-FLT 5/16 FLAT WASHER
