LPOD C-/Ku-Band Outdoor Amplifier/ Block Up Converter (BUC) Revision 3
Appendix A MN-LPOD
A–4
Figures and tables on the pages that follow illustrate the CEFD kits currently available for
assembling LPOD PS-1 or PS-2 1:1 redundant systems:
FIGURE(S)
TABLE
(BOM)
CEFD PART NO. DESCRIPTION
N/A A-1 KT-0000116
KIT, Rx SPLITTER & CABLES
A-1, A-2 A-2 KT-0000098
KIT, Rx SWITCH, LPOD C-BAND
A-3, A-4 A-3 PL/7596-1
KIT, Rx SWITCH, LPOD Ku-BAND
A-5, A-6 A-4 KT-0000104
KIT, MTG & CABLE,
Tx SWITCH, C-BAND, WAVEGUIDE OUTPUT, 1:1, LPOD PS-1
A-7, A-8 A-5 KT-0000090
KIT, MTG & CABLE, Tx SWITCH, C-BAND, COAX OUTPUT, 1:1, LPOD PS-1
A-9, A-10 A-6 KT-0000089
KIT, MTG & CABLE, Tx SWITCH, Ku-BAND, 1:1, LPOD PS-1
A-11, A-12 A-7 KT-0000091 KIT, MTG & CABLE, Tx SWITCH, C-BAND, 1:1, LPOD PS-2
Table A-1. KT-0000116 LPOD Rx Splitter / Cable Kit BOM
KT-0000116 LPOD Rx Splitter / Cable Kit
ITEM QTY CEFD PART NO. DESCRIPTION
N/A 2
CA/RF0097 CABLE ASSY, CONNECTOR, CSAT-7075 OUTPUT RF, ROHS
N/A 2 FP-0000580 SPACER PLATE, RF SPLITTER / COMBINER
N/A 2
HW/4-40X1.25PH #4-40 X 1.25 P.H. PHIL SCREW, S.S.
N/A 2 HW/4-FLT #4 FLAT WASHER S.S.
N/A 2
HW/4-SPLIT
#4 SPLIT LOCK WASHER S.S.
N/A 6 HW/TW14.5HDBLK CABLE TIE, 14.5", HEAVY DUTY, BLACK
N/A 1
RF-0000105 RF POWER SPLITTER/COMBINER, 2-WAY, 0 DEGREES, 1-2GHZ
Table A-2. KT-0000098 LPOD C-Band Rx Switch Kit BOM
KT-0000098 LPOD C-Band Rx Switch Kit
ITEM QTY CEFD PART NO. DESCRIPTION
1 1
28P1084 QP RF ADAPTER, N (FEM) TO CPRG229 W/G GROOVED FOR 1/2 GASKET
2 1 CN/CX50NMALE CONNECTOR, CN-50-OHM,N, MALE TERMINATION
3 1
SW/WGS28V-229SM
WAVEGUIDE, CPR229 GROOVED, +28V SEALED (MS3116F10-6S MATING CONN)
4 4 GA/GSKTCPR229FULL GASKET, CPR229, FULL THK
5 12
03P1078 BOLT, 1/4-20 X 3/4 HEX, SS
6 32
HW/1/4-20X5/8HEX SCREW, 1/4-20 X 5/8 HEX,
SS
7 42
HW/1/4-FLT 1/4 FLAT WASHER
8 42
HW/1/4-SPLIT 1/4 SPLIT WASHER
Table A-3. PL/7596-1 LPOD Ku-Band Rx Switch Kit BOM
PL/7596-1 LPOD Ku-Band Rx Switch Kit
ITEM QTY CEFD PART NO. DESCRIPTION
1 1
SW/WGS28V-75SB
WAVEGUIDE, WR75, +28VDC, SEALED//SIDE & BOT MNT
2 16 HW/6-32X1/2SHCS #6-32X1/2 SOCKET HD CAP SCREW S.S.
3 1
KT/2819 KIT WAVEGUIDE ABS 1:1 KU-BAND
4 1
KT/2820 KIT WAVEGUIDE ABS 1:2 KU-BAND
5 2
99D1483
A
SSY, WAVEGUIDE WR75
6 1
FP/6072 PLATE SHORTING WR75G
7 1 RF/TRF-KU-WR75G RF TRANSMIT REJECT, WR-75, GROOVED
8 16
HW/6-FLT #6 FLAT WASHER S.S.
9 16 HW/6-SPLIT #6 SPLIT LOCK WASHER S.S.
10 2
RF/TBD RF, BIN TO BE DETERMINED
11 4
GA/GSKTWR75HALF
GASKET, WR75, HALF THK
