Comtech EF Data LPOD - Table A-4. KT-0000104 LPOD PS-1 1:1 Redundancy Kit BOM

LPOD C-/Ku-Band Outdoor Amplifier/ Block Up Converter (BUC) Revision 3
Appendix A MN-LPOD
A–10
Table A-4. KT-0000104 LPOD PS-1 1:1 Redundancy Kit BOM
KT-0000104 LPOD PS-1 C-Band (Waveguide) 1:1 Redundancy Kit (as per Figure
A
-2)
ITEM QTY CEFD PART NO. DESCRIPTION
1 4 FP-0000534 BRACKET, MOUNTING, LPOD PS-1
2 2 FP-0000542 CHANNEL, DUAL, UNISTRUT, 1:1 RDNT, LPOD PS-1
3 1 FP-0000537 BRACKET, UNIVERSAL, 1:1 RDNT, LPOD PS-1
4 1 FP-0000544 BRACKET, MOUNTING, CABLE, MOLDED JUNCTION
5 2 FP-0000580 SPACER PLATE, RF SPLITTER / COMBINER
6 1 FP-0000645 BRACKET, SUPPORT, 1:1 RED., LPOD PS-1
10 2 CA/RF0097 CABLE ASSY, ROHS CONNECTOR, CSAT-7075 OUTPUT RF
11 1 HW/CAP-SS14 HW DUST COVER,RECEPTACLE W/CHAIN & RING, NON-SHORTING, SIZE 14, SS
12 2 CA/6357-2 CABLE, ROHS TX (2FT)
20 1 SW/WGS28V-137S SW WAVEGUIDE, CPR137, +28V SEALED
21 1 FP/WG0034 PNQ, WAVEGUIDE TERMINATION, SMALL FINS
22 1 RF-0000105 RF POWER SPLITTER/COMBINER, 2-WAY, 0 DEGREES, 1-2GHZ
23 4 GA/CPR-137-R-H-C GASKET, D SHAPE, CPR-137, HALF THICKNESS, CONDUCTIVE
24 2 FP/5683 WELDMENT, WAVEGUIDE ADAPTER CPRG137 TO N
30 8 HW/1/4-20X1/2FH SCREW, 1/4-20 X 1/2 FH PHIL, 82, UCUT, SS
31 10 HW-0000070 SCREW, HEX, FLG, 0.375-16 X 0.750, SST, SERR
32 10 HW/3/8SPRINGNUT SPRINGNUT, 3/8-16, SHORT SPRING, SST (P3300)
33 2 HW/4-40X1.38PH SCREW, #4-40 X 1/38 P.H. SS
34 2 HW/4-SPLIT WASHER, #4 SPLIT LOCK S.S.
35 2 HW/4-FLT WASHER, #4 FLAT S.S.
37 4 HW/6-32X5/16P.H SCREW, #6-32 X 5/16 P.H.
38 4 HW/6-SPLIT WASHER, #6 SPLIT LOCK S.S.
39 4 HW/6-FLT WASHER, #6 FLAT S.S.
40 26 HW/10-32X1/2SH SCREW, #10-32X1/2 SOCKET HEAD CAP
41 14 HW/10-32X5/8SHC SCREW, #10-32 X 5/8 SOCKET HEAD CAP
42 32 HW/10-SPLIT WASHER, #10 SPLIT LOCK S.S.
43 32 HW/10-FLT WASHER, #10 FLAT S.S.
49 12 HW/TW14.5HDBLK HW CABLE TIE, 14.5", HEAVY DUTY, BLACK
50 2 HW/8-32X1/2SHCS SCREW, #8-32 X 1/2 SOCKET HEAD CAP S.S.
51 4 HW/8-FLT WASHER, #8 FLAT S.S.
52 2 HW/8-SPLIT WASHER, #8 SPLIT LOCK S.S.
53 2 HW/8-32HEXNUT HEX NUT, #8-32 S.S.
