LPOD C-/Ku-Band Outdoor Amplifier/Block Up Converter Revision 3
System Connections, Installation, and Operation MN-LPOD
2–5
2.2.4.3 LPOD PS-2 J3 48VDC Power Main Option
The connector type and mating connector specification unique to the LPOD PS-2 48 VDC power
interface option, and the pin assignments (Table 2-6) are as follow
s:
Unit Connector Type: CEFD P/N CN-0000288 (ITT Cannon CA3102E20-15SB-F80A232).
Supplied Mating Connector: CEFD P/N CN-0000289 (ITT Cannon CA3106E20-15SB-F80A232).
Table 2-6. LPOD PS-2 ‘J3 PWR IN’ 48VDC Pin Assignments
Pin LPOD PS-1 Assignment
A
V+
B
V+
C
NO CONNECT
D NO CONNECT
E V-
F V-
G GROUND (Note 2)
Notes:
1. Use 12 AWG wire to each of the appropriate pins, according to the
individual pin assignments.
2. As an alternative, the ground connection can be made to the unit's
external ground stud.
