ITEM QTY CEFD PART NO. DESCRIPTION
1 4 FP-0000534 BRACKET, MOUNTING, LPOD PS-1
2 2 FP-0000542 CHANNEL, DUAL, UNISTRUT, 1:1 RDNT, LPOD PS-1
3 1 FP-0000537 BRACKET, UNIVERSAL, 1:1 RDNT, LPOD PS-1
4 1 FP-0000548 WAVEGUIDE, Ku, WR-75, GRVD FLGS, E TO H TO FLEX, LH, 1:1, PS-1
5 1 FP-0000549 WAVEGUIDE, Ku, WR-75, GRVD FLGS, E TO H TO FLEX, RH, 1:1, PS-1
6 1 FP-0000544 BRACKET, MOUNTING, CABLE, MOLDED JUNCTION
7 2 FP-0000580 SPACER PLATE, RF SPLITTER / COMBINER
8 1 FP-0000645 BRACKET, SUPPORT, 1:1 RED., LPOD PS-1
11 2 CA/RF0097 CABLE ASSY, ROHS CONNECTOR, CSAT-7075 OUTPUT RF, ROHS
12 1 HW/CAP-SS14 DUST COVER,RECEPTACLE,NON-SHORTING,SIZE 14,S.S,W/CHAIN & RING
20 1 SW/WGS28V-75SB WAVEGUIDE, WR75, +28VDC, SEALED//SIDE & BOT MNT
21 1 RF/TERM-11923-5 RF TERMINATION, WR75G, 14-14.5GHz, 1.05:1 VSWR, 150W
22 1 RF-0000105 RF POWER SPLITTER/COMBINER, 2-WAY, 0 DEGREES, 1-2GHZ
23 6 GA/WR75-R-H-C GASKET, O RING, WR-75, HALF THICKNESS, CONDUCTIVE
24 12 HW/TW14.5HDBLK CABLE TIE, 14.5", HEAVY DUTY, BLACK
30 8 HW/1/4-20X1/2FH SCREW, 1/4-20 X 1/2 FH PHIL, 82, UCUT, S.S
33 10 HW-0000070 SCREW, HEX, FLG, 0.375-16 X 0.750, S.S, SERR
34 10 HW/3/8SPRINGNUT SPRINGNUT, 3/8-16, SHORT SPRING, S.S (P3300)
35 2 HW/4-FLT #4 FLAT WASHER S.S.
36 2 HW/4-SPLIT #4 SPLIT LOCK WASHER S.S.
37 2 HW/4-40X1.38PH #4-40 X 1/38 P.H. PHIL SCREW S.S
39 28 HW/6-FLT #6 FLAT WASHER S.S.
40 28 HW/6-SPLIT #6 SPLIT LOCK WASHER S.S.
41 4 HW/6-32X5/16P.H #6-32 X 5/16 PHILLIPS SCREW
42 20 HW/6-32X1/2SHCS #6-32X1/2 SOCKET HD CAP SCREW S.S
43 4 03P1111 SCREW, 6-32x9/16, SOCKET HD S.S
44 2 HW/8-32X1/2SHCS #8-32 X 1/2 SOCKET HEAD CAP SCREW S.S.
45 4 HW/8-FLT #8 FLAT WASHER S.S.
46 2 HW/8-SPLIT #8 SPLIT LOCK WASHER S.S.
47 2 HW/8-32HEXNUT #8-32 HEX NUT S.S.
