LPOD C-/Ku-Band Outdoor Amplifier / Block Up Converter (BUC) Revision 3
Introduction MN-LPOD
1–10
1.5.4 Environmental
Temperature
Operating
Standard
-40º to 122ºF (-40º to 55ºC)
Optional
-40º to 140ºF (-40º to 60ºC)
Storage
-67º to 167ºF (-55º to 75ºC)
Humidity
100% condensing rain 2” per hour
Altitude
10,000 AMSL
Shock
Normal commercial shipping and handling
1.5.5 Physical
Weight
PS-1
20 lbs. (9.1 kg) Nominal
PS-2
47 lbs (21.32 kg) Nominal
Dimensions
(excluding connectors)
PS-1
(See Figure 1-4 or 1-5)
12.65 x 6.26 x 7.37 in.
(321.3 x 159 x 187.2 mm)
PS-2
(See Figure 1-6)
16.18 x 8.80 x 9.78 x in.
(427 x 223.5 x 248.4 mm)
Connectors
IF/RF Input
Type N, female
RF Output
PS-1/PS-2 Ku-Band: WR75G
PS-1, C-Band: Type N, female
PS-2, C-Band: CPR137G
LNB Bias
Type N, Female
M&C/Ethernet/
Redundancy Switches
19-pin MS style (single integrated cable assembly available,
dependent upon configuration)
