34 Mounting and installation work
– The minimum bend radius for xed piping is 5 x steam pipe inside diameter.
– Connection of the steam pipes to the steam distributor and the steam outlet connector on the steam
tank is effected with pieces of steam hose with an appropriate length (the length of the steam hose
connected to the steam outlet of the steam generator must be min. 1,000 mm) secured with hose
clamps.
– Important! Allowance must be made for a pressure loss of approx. 100 Pa per meter length or
per 90° bend.
