Contec CMS8000 Manual

-
-
-
- 116 -
-
-
-



 Mainstream
Mainstream
Mainstream
Mainstream
Figure
Figure
Figure
Figure 16-3
16-3
16-3
16-3 MainStream
MainStream
MainStream
MainStream Module
Module
Module
Module
1. The mainstream module can only be used for intubated patient.
2.
S et the "work mode" to "measure"in the submenu "OTHER SET" of "CO2 MENU"
3.
Connect the module to the monitor .
4. Place the module above on the adapter .
5. Perform airway adapter zero .
6. C onnect the airway adapter into the patient's airway.
7. Capnogram, displayed in less than 15 seconds at an ambient temperatureof 25 º C, full
specifications within 2 minutes
Warning
Warning
Warning
Warning
 Do not use the accessory if the packaging or the internal accessory is damaged. Return it to the
manufacturer.
 The sidestream sampling line is disposable. It should not be disinfected for reuse or cross-used by
different patients.



 In the long-term use, dust or other substances may lower the air permeability of the filter material
in the sample cell and may block the airway. In this situation, the sampling line must be replaced.
 N o routine user calibration required. For mainstream,a n airway adapter zero is required when
changing to a different style of airway adapter.

Contec CMS8000 Specifications

General

Category	Medical Equipment
Device Name	Contec CMS8000
Type	Patient Monitor
ECG Lead Mode	3-lead or 5-lead
Resolution	800 x 600
Power Supply	AC 100-240V, 50/60Hz
Battery	Rechargeable lithium battery
Operating Temperature	5°C to 40°C
Storage Temperature	-20°C to 55°C
Display	TFT LCD
Screen Size	12.1 inches
Parameters	ECG, RESP, NIBP, SpO2, TEMP, PR
Interface	Ethernet, Nurse call
Humidity	15% to 95% non-condensing
Battery Life	Approximately 4 hours
