2. Overview
Table 2.1. Functional Specifications < 2 / 2 >
Model IPC-PT/L630S(PCI)C IPC-PT/L630S(PCI)CP IPC-PT/H630X(PCI)C IPC-PT/H630X(PCI)CP
Keyboard I/F PS/2-type keyboard-compatible (6pin, MINI DIN connector)
Mouse I/F PS/2-type mouse-compatible (6pin MINI DIN connector)
RAS function
WDT: 1sec - 255sec (RESET or external output is allowed at time expiration)
Remote reset: External input signal
Expansion board slot None Shared PCI slot x 2,
Installable board length
: 240mm (Max.)
None Shared PCI slot x 2,
Installable board length
: 240mm (Max.)
RTC/CMOS Lithium backup battery life: 10 years or more
Input supply
voltage
Automatically switched between 85 - 132 VAC and 170 - 265 VAC (47 - 63 Hz)
Current
consumption
60VA (Max.) 110VA (Max.) 65VA (Max.) 115VA (Max.)
Power
supply
Expansion
board
power-supply
capacity
None
+5V: 2A(1A x 2 Slot),
-5V: Not supplied,
+12V: 0.3A,
-12V: 80mA
None
+5V: 2A(1A x 2 Slot),
-5V: Not supplied,
+12V: 0.3A,
-12V: 80mA
External dimensions
(mm)
370(W) x 79(D) x
307(H)
(Board depth)
370(W) x 139(D) x
307(H)
(Board depth)
428(W) x 79(D) x
336(H)
(Board depth)
428(W) x 139(D) x
336(H)
(Board depth)
Waterproofing,
dustproofing
IP65, fornt
Weight Approx. 6.6kg Approx. 7.5kg Approx. 7.6kg Approx. 8.5kg
*1
A 256 MB memory module is plugged in one socket.
*2 Using the DVI-analog RGB adapter (accessory bundled), one more unit of an ordinary analog RGB input display
can be added. Note that Panel Link input displays cannot be connected.
