2. Overview
2.
Overview
Specifications
Table 2.1. Functional Specifications < 1 / 2 >
Model IPC-PT/L630S(PCI)C IPC-PT/L630S(PCI)CP IPC-PT/H630X(PCI)C IPC-PT/H630X(PCI)CP
LCD type
12.1-inch TFT color LCD,
SVGA (800 x 600 dots)
15-inch TFT color LCD, XGA
(1024 x 768 dots)
Display
Number of
colors
260,000
Resolution 4096 x 4096
(emulated in 800 x 600 mode)
4096 x 4096
(emulated in 1024 x 768 mode)
Touch
panel
Detection
method
Analog resistive
Backlight ON/OFF Enabled (software control)
CPU Low Voltage Intel(R) Pentium(R) III Processor 800MHz, FSB133MHz
Chip set Intel(R) 815E
L2 Cache 512KB
Main
memory
256 MB standard *1 / Max. 256MB (3.3V 144pin SO-DIMM PC133 Socket x 2)
Memory
BIOS ROM 128KB E0000H - FFFFFH (Phoenix)
Controller Intel 815E (Built into the controller)
Video RAM Main memory shared
Video BIOS 48KB (C0000H - CBFFFF)
Video
Display I/F DVI-I 29pin *2
Audio AC97 compliant
LINE IN: φ3.5 Stereo mini jack
Full-scale input level 1.3Vrms(Typ.)
LINE OUT: φ3.5 Stereo mini jack
Full-scale input level 1.0Vrms(Typ.)
MIC UN: φ3.5 monaural mini jack
Full-scale input level 1.3Vrms(Typ.)
FDD I/F Equipped with a dedicated 26pin, half-pitch connector: 2 modes (Optional FDD: PC-FDD25BH)
Primary
Ultra DMA/100
2.5 inch IDE HDD or silicon disk drive: 1 internal unit
(One more unit can be added. Either of the two must be a silicon disk drive.)
IDE
HDD
I/F
Secondary
Equipped with a dedicated 40pin, half-pitch connector
(for connection of an optional CD-ROM) (bottom)
Serial I/F
RS-232C(general-purpose): 2ch (SERIAL PORT1,2) 9pin, D-SUB connector
RS-232C(touch panel): 1ch (SERIAL PORT3)
RS-422/485(general-purpose): 1ch (SERIAL PORT4) [inside the RAS connector]
Parallel I/F Bi-directional, Centronics-compliant, 25pin D-SUB connector
I/F Ethernet 100BASE-TX/10BASE-T RJ-45 connector LAN
Controller Intel ICH2 integrated
PC card slot
PCMCIA Type I, II x 2 or III x 1 (Startup from ATA card not allowed)
CardBus correspondence
USB I/F 2ch (USB 1.1)
User’s Manual
9
