4. BIOS Setup
Advanced Window
Reset Configuration Data: [No]
Installed O/S: [Other]
PCI IRQ
PCI/PMP ISA UMB Region Exclusion
PCI/PMP ISA DMA Resource Exclusion
I/O Device Configuration
ISA Bridge
Legacy USB Support: [Disabled]
Audio Device: [Enabled]
Large Disk Access Mode: [DOS]
Local Bus IDE adapter: [Both]
WDT Output to P02: [Disabled]
WDT Power-on State: [Off]
WDT Time-up State: [On]
PCIC Irq Mode: [Continous]
BIOS DDC: [Enabled]
Start Wait: [Disabled]
PhoenixBIOS Setup Utility
Main Advanced Security Power PC_Health Boot Exit
Item Specific Help
Select 'Yes' if you
want to clear the
Extended System
Configuration
Data (ESCD) area.
F1 Help Select Item -/+ Change Values F9 Setup Defaults
Esc Exit ←→ Select Menu Enter Select Sub-Menu F10 Save and Exit
Figure 4.4. Advanced Window (Factory Settings)
Reset Configuration Data :Resets the system configuration data
stored in BIOS ROM. The data will be
reset by setting this field to [Yes] and
exiting BIOS Setup while saving the
changes you made. This field reverts to
[No] automatically the next time you
invoke BIOS Setup. Before reinstalling
the OS, be sure to set the field to [Yes].
Installed OS : Normally, set to "Other."
PCI IRQ : Displays the PCI IRQ setup submenu.
You can assign IRQs to individual PCI
slots. All PCI slots are connected to
IRQ10 by default.
PCI/PNP ISA UMB Region Exclusion:
Start PCI/PNP ISA UMB Region
Exclusion as shown above.
You can reserve UMB areas for devices.
All UMB areas are unallocated by
default. Up to 32 kilobytes from
addresses D0000 - D7FFFH can be
allocated.
User’s Manual
35
