6. Touch Panel
6.
Touch Panel
The PANECON-PC is equipped with an analog touch panel which
enables keyboard-less, mouse-less operations.
Table 6.1. Touch panel specifications
Model
IPC-PT/L630S(PCI)C
IPC-PT/L630S(PCI)CP
IPC-PT/H630X(PCI)C
IPC-PT/H630X(PCI)CP
Detection method Analog resistive
Active area 246 x 184.5mm 304.1 x 228.1mm
Surface treatment Nonglare
Resolution 4096 x 4096 (emulated in 800 x 600 mode) 4096 x 4096 (emulated in 1024 x 768 mode)
Operating lifetime 1 million touches minimum
(as tested by mechanical touching under 300g of force at a rate of two presses per
second)
Touch panel serial interface
The PANECON-PC uses a serial port (SERIAL 3) for
communication with the touch panel. You can use BIOS Setup
(described in Chapter 4) to assign I/O addresses and an IRQ or to
disable it. (The I/O addresses or IRQ cannot be shared with any
other device.)
Visit the CONTEC web site to download the touch panel driver
(IPC-SLIB-01) for the OS running on your PANECON-PC.
For the download, see Chapter 7 “List of Options".
Table 6.2 SERIAL3 I/O address, interrupt
COM I/O address Interrupt
1 3F8h - 3FFh
2 2F8h - 2FFh
3 3E8h - 3EFh
4 2E8h - 2EFh
IRQ 3
IRQ 4
IRQ 5
IRQ 7
IRQ 9
IRQ 10
IRQ 11
IRQ 15
BIOS Default Factory Settings
Serial port C: COM3 (3E8h-3EFh), IRQ 5
User’s Manual
83
