3. Hardware Setup
Installing the Hard Disk
(1) Connect the provided HDD cable to the hard disk (silicon disk).
Note!
Connect the HDD cable in alignment with pins from the left
end of the connector on the HDD side.
Four master/slave setting pins are left unconnected on the
right side.
Be aware that connecting the power with the
connector misaligned will damage the cable.
(2) By threading the cable through the hole on the base of the hard
disk bracket, fasten the disk to its bracket using four screws.
- Fasten the disk using the outer or inner hole depending on
the model you are using. (The figure below shows an
example that uses the inner screw hole.)
Note!
When installing two drives in the HDD bracket, you can
place either the hard disk drive (HDD) or silicon disk drive
(SDD) in the upper position and only the SDD in the lower
position. If you install two disk drives, set their jumpers
according to the instructions in their manuals to assign them
as the master and slave devices.
