4. BIOS Setup

BIOS Setup

BIOS setup sets various settings during startup. When using the

system for the first time, be sure to run BIOS setup. Once set up, the

specified details will be backed up.

Starting the Setup Screen

When you turn on the system power supply, the PANECON-PC

displays the following initial screen as long as the system is normal.

Press the <F2> key at the keyboard.

Phoenix BIOS 4.0 Release 6.0

IPC-BX/M630(PCW), IPC-Px/x630(PCW) series BIOS Ver. x.xx.

CPU = Pentium III(R) Tualatin 512K-LP(133MHz/1.150) processor 800MHz

Memory Speed = PC133

635K System RAM Passed

509M Extended RAM Passed

512K Cache SRAM Passed

System BIOS Shadowed

Video BIOS shadowed

Figure 4.1. Initial Screen

Keystrokes

The following is a list of major key functions you can use during

BIOS setup:

Table 4.1. Key Function List

Key to press

Function

→, ← Moves the main menu.

↑, ↓ Moves between items to be set.

<Tab> Moves within items to be set.

<Shift>+<Tab> Moves in the direction opposite to <Tab>.

<Spacebar> Changes details to be set.

+ Functions the same as <Spacebar>.

- Changes in the direction opposite to the + key.

<Enter> Opens submenus.

<Esc> Moves to the Exit window.

<F9> Resets all to defaults.

<F10> Saves set values and exits setup.
