4. BIOS Setup
PC-Health Window
Hardware Monitor Setup
Thermal1_0 (System1): +32
°
C / +89
°
F
Thermal1_1 (CPU): +56
°
C / +132
°
F
FAN_0 : 0 RPM
FAN_1 : 0 RPM
+5V : +4.97V
+3.3V : +3.28V
F1 Help
↓
Select Item -/+ Change Values F9 Setup Defaults
Esc Exit
←→
Select Menu Enter Select Sub-Menu F10 Save and Exit
PhoenixBIOS Setup Utility
Main Advanced Security Power PC_Health Boot Exit
Item Specific Help
↓
Figure 4.8. PC-Health Window (Factory Settings)
Hardware Monitor Setup : Start Hardware Monitor Setup as shown
above. Although you can make fan
settings, leave this field at the default
because the PANECON-PC uses no
CPU fan.
Thermal_0 (System1) : Displays the temperature detected by
the Thermal_0 temperature sensor.
Thermal_1 (CPU) : Displays the temperature detected by
the CPU temperature sensor.
FAN_0 : Reads “0 RPM” as this PANECON-PC
uses no Fan 0.
FAN_1 : Reads “0 RPM” as this PANECON-PC
uses no Fan 0.
+5V : Displays a voltage of +5 V.
+3.3V : Displays a voltage of +3.3 V.
42
