5. Each Component Function
S1
Leave all the S1 bits untouched as they are used by the
system.
IPC-PT/L630S(PCI)C, CP IPC-PT/H630X(PCI)C, CP
S1
ON
12345678
S1
ON
12345678
Figure 5.20. Factory Settings
Reset Switch
The PANECON-PC is equipped with a hardware reset switch. To
prevent it from being pressed by mistake, the switch is designed to
be difficult to press. Use a pointed object to push the switch with.
