5. Each Component Function
Control of Transmitted Data in Half-Duplex Mode
In half-duplex mode, the transmission buffer needs to be controlled
in order to prevent collision of transmitted data. The
PANECON-PC uses RTS and controls the buffer with modem
control register's bit 1. Transmission and reception gate control by
the register setting of port address 4006h and 4007h is allowed only
for the RS-422/485 (Serial port D). For more information see
section, "General-purpose I/O and Remote Reset" in Chapter 5.
Modem control register
(Set I/O address +4H) bit 1 :0 … RTS is High.
(Disable transmission)
1 … RTS is Low.
(Enable transmission)
I/O Addresses and Instructions
The I/O addresses and instructions of COM1 are shown next.
Table 5.9. I/O Addresses
I/O address DLAB Read/Write Register
0 W Transmitter holding register THR
R Receive buffer register RBR
03F8H
1 W Divisor latch register DLL
1 W Divisor latch register DLM 03F9H
0 W Interrupt enable register IER
03FAH X R Interrupt ID register IIR
03FBH X W Line control register LCR
03FCH X W Modem control register MCR
03FDH X R Line status register LSR
03FEH X R Modem status register MSR
03FFH X R/W Scratch register SCR
DLAB (Divisor Latch Access Bit) : The value in bit 7 of the line
control register
User’s Manual
53
