Control Techniques Epsilon EP-P User Manual

2 Epsilon EP-P Drive Reference Manual
www.controltechniques.com Revision: A4
Figure 2: Epsilon EP-209 Drive Feature Location
Figure 3: Epsilon EP-216 Drive Feature Location
Shunt Connector (J8)
Model Number, Part Number,
Revision and Serial Number Label
24 Vdc Logic Power
Supply Connections
Status/Diagnostic Display
Motor Power Connections
Reset Button
AC Power Connector
Serial
Connectors (J2)
Ethernet Connector (J4)
(EP-Pxx only)
DeviceNet Connector (J9)
(EP-PDN only)
Digital I/O Connector (J3)
Encoder Feedback Connector (J6)
Sync Input Connector (J10)
Analog/Sync Output
Connector (J5)
Profibus Connector (J13)
(EP-PPB only)
Shunt Connector (J8)
24 Vdc Logic Power
Supply Connector
Status/Diagnostic Display
AC Power Connections
Motor Power Connections
Reset Button
Serial
Connectors (J2)
Ethernet Connector (J4)
(EP-Pxx only)
Ethernet Connector (J9)
(EP-PDN only)
Digital I/O Connector (J3)
Model Number, Part Number,
Revision and Serial Number Label
Encoder Feedback Connector (J6)
Sync Input Connector (J10)
Analog/Sync Output
Connector (J5)
Profibus Connector (J13)
(EP-PPB only)
