Epsilon EP-P Drive Reference Manual 209
Revision A4 www.controltechniques.com
8.3 XV Motor Cables
8.3.1 XTMDS
PIN 1
GRN/YEL
BRN
BLK
BLU
2
3
4
1
BRAID SHIELD FORM WIRE
R
S
T
PE/GND
1
3
2
4
REAR VIEW OF
CONNECTOR
