218 Epsilon EP-P Drive Reference Manual
www.controltechniques.com Revision: A4
8.5 SYNC Cables
8.5.1 ENCO Cable
SOLDER SIDE
Socket
J
C
F
E
D
I
G
H
A
B
GND
+5 V
Shield
A/
Z/
Z
B/
B
A
P
P
P
P
YEL/WHT
RED/WHT
BLK/WHT
BLU/WHT
BLU
YEL
DRAIN WIRE
BLK
RED
J
B
I
H
A
C
F
D
