Epsilon EP-P Drive Reference Manual 225
Revision A4 www.controltechniques.com
9 Glossary
µs
Microsecond, which is 0.000001 seconds.
A
Amps.
Amplifier
Servo Drive.
ARMS
Amps Root Mean Squared (RMS).
Axis
The full system to control in a single motor shaft. A single Epsilon EP-P drive can denote an
axis.
AWG
American Wire Gauge.
Baud Rate
The number of binary bits transmitted per second on a serial communications link such as RS-
232. (1 character is usually 10 bits.)
Check Box
In a dialog box, a check box is a small box that the user can turn “On” or “Off” with the mouse.
When “On” it displays an X in a square; when “Off” the square is blank. Unlike option (radio)
buttons, check boxes do not affect each other; any check box can be “On” or “Off”
independently of all the others.
Complex Motion
A string of multiple motion commands and logical instructions that form a repeatable operation.
For the Epsilon EP-P drive, the configuration file defines complex motion by setups, functional
assignments and programs.
Compound Motion
The combination of indexes in a row in which the deceleration ramp of the first index goes to
the velocity of the secondary index. The first index must be initiated within a program
(Index.#.CompoundInitiate).
Configuration
The user-created application. It can be saved as a disk file or downloaded to configure the
Epsilon EP-P drive. It includes all the user-defined setup, assignments and programs.
CRC
Cyclical Redundancy Check, the data transfer error checking mechanism.
Destination
A function (i.e., Stop, Preset) that may be assigned to an input line. In Epsilon EP-P drive, the
input function is connected to the action through click and drag operations in PowerTools
Software on the Assignment View.
