Parameter
structure
Keypad and
display
Parameter x.00
Parameter description
format
Advanced parameter
descriptions
Serial comms
protocol
Performance
Menu 6
Mentor MP Advanced User Guide 103
Issue Number: 4 www.controltechniques.com
See Pr 6.18.
If Pr 6.28 = 0, the powered-up clock is used for time stamping.
If Pr 6.28 = 1, the run time clock is used for time stamping.
It should be noted that changing this parameter clears the trip and trip time logs.
This bit shows whether the drive is in the enable state or not.
Generally this will reflect the state of the enable input and shows the same value as Pr 8.09. However the disabled state can be forced by inputs
routed to this parameter. Pr 8.09 will always follow the enable input state but Pr 6.29 will be held at zero, indicating that the drive is forced into the
disable state by an input.
See Pr 6.34 for description.
See Pr 6.34 for description.
See Pr 6.34 for description.
See Pr 6.34 for description.
6.27 Time before filter change due
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 11
Range 0 to 30,000 hrs
Update rate Background read
6.28 Select clock for trip log time stamping
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate Background read
6.29 Hardware enable
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Update rate 4 ms write
6.30 Sequencing bit: Run forward
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate 4 ms read
6.31 Sequencing bit: Jog
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate 4 ms read
6.32 Sequencing bit: Run reverse
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate 4 ms read
6.33 Sequencing bit: Forward/reverse
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate 4 ms read
