Menu 6
Parameter
structure
Keypad and
display
Parameter x.00
Parameter description
format
Advanced parameter
descriptions
Serial comms
protocol
Performance
102 Mentor MP Advanced User Guide
www.controltechniques.com Issue Number: 4
See description for Pr 6.20.
The run time clock increments when the drive output stage is active to indicate the number of minutes that the drive has been running since leaving
the manufacturing plant. This clock may be used for time stamping the trip log if Pr 6.28 = 1.
This parameter is used in conjunction with Pr 6.23.
See description for Pr 6.22.
Pr 6.24 and Pr 6.25 form the energy meter that indicates energy supplied to/from the drive in MWh and kWh.
For motor control modes a positive value indicates net transfer of energy from the drive to the motor. The energy meter is reset and held at zero when
Pr 6.17 is one.
This parameter is used in conjunction with Pr 6.25.
See description for Pr 6.24.
Instantaneous read out of the cost/hour of running the drive. This requires Pr 6.16 to be set up correctly.
6.21 Powered-up time: hours.minutes
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
21 1 1 11
Range 0 to 23.59 Hours.Minutes
Update rate Background write
6.22 Run time: years.days
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
31 1 1 11
Range 0 to 9.364 Years.Days
Update rate Background write
6.23 Run time: hours.minutes
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
21 1 1 11
Range 0 to 23.59 Hours.Minutes
Update rate Background write
6.24 Energy meter: MWh
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1 1 1
Range ±9999 MWh
Update rate Background write
6.25 Energy meter: kWh
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
21 1 1 1
Range ±999 kWh
Update rate Background write
6.26 Running cost
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range ±32,000
Update rate Background write
