Control Techniques Mentor MP User Manual

Menu 7
Parameter
structure
Keypad and
display
Parameter x.00
Parameter description
format
Advanced parameter
descriptions
Serial comms
protocol
Performance
110 Mentor MP Advanced User Guide
www.controltechniques.com Issue Number: 4
When analog input 3 is in thermistor mode the display indicates the resistance of the thermistor as a percentage of 10k Ω
If the temperature displayed in Pr 7.04 exceeds the trip threshold for the parameter an Oht2 trip is initiated. This trip can only be reset if the parameter
that has caused the trip falls below the trip reset level. If the temperature exceeds the alarm level, a "hot" alarm is displayed. If the temperature for any
of these monitoring points is outside the range -20
ο
C to 150
ο
C, it is assumed that the monitoring thermistor has failed and a hardware fault trip is
initiated (HF27), details are given in the following table.
Power stage temperature 1 (Pr 7.04) in
ο
C.
7.01
{in02, 0.82}
T5/6 analog input 1
Coding
BitSP FI DETEVMDPNDRANCNVPTUSRWBUPS
21 1 1
Range ±100.00 %
Update rate 4 ms write
7.02
{in03, 0.83}
T7 analog input 2
7.03
{in04, 0.84}
T8 analog input 3
Coding
BitSP FI DETEVMDPNDRANCNVPTUSRWBUPS
11 1 1
Range ±100.0 %
Update rate 4 ms write
7.04 Power circuit temperature
Coding
BitSP FI DETEVMDPNDRANCNVPTUSRWBUPS
111
Range
-128 to 127
ο
C
Update rate Background write
Drive O.ht2 Trip temperature Release from O.ht2 Warning temperature
MP25A4(R)
100 95 90
MP45A4(R)
MP75A4(R)
MP105A4(R)
MP155A4(R)
MP210A4(R) 94 90 85
MP25A5(R)
100 95 90
MP45A5(R)
MP105A5(R)
MP155A5(R)
MP210A5(R) 94 90 85
MP350A4(R)
105 100 95
MP420A4(R)
MP550A4(R) 100 95 90
MP700A4(R)
105 100 95
MP825A4(R)
MP900A4(R) 100 95 90
MP1200A4(R)
110 100 95
MP1850A4(R)
MP350A5(R) 100 95 90
MP470A5(R) 81 75 70
MP700A5(R) 100 95 90
MP825A5(R) 94 90 85
MP1200A5(R)
110 100 95
MP1850A5(R)
MP350A6(R) 100 95 90
MP470A6(R) 81 75 70
