Control Techniques Mentor MP User Manual

Parameter
structure
Keypad and
display
Parameter x.00
Parameter description
format
Advanced parameter
descriptions
Serial comms
protocol
Performance
Menu 7
Mentor MP Advanced User Guide 111
Issue Number: 4 www.controltechniques.com
The following modes are available for the analog inputs 2 and 3.
In modes 2 and 3 a current loop loss trip is generated if the input current falls below 3 mA.
In modes 4 and 5 the analog input level goes to 0.0 % if the input current falls below 3 mA.
Modes 7, 8 and 9 are only available with analog input 3.
MP700A6(R) 100 95 90
MP825A6(R) 94 90 85
MP1200A6(R)
110 100 95
MP1850A6(R)
7.08 T5/6 analog input 1 scaling
Coding
Bit SP FI DETEVMDPNDRANCNVPTUSRWBUPS
3 111
Range 0.000 to 40.000
Default 1.000
Update rate Background read
7.09 T5/6 analog input 1 invert
Coding
Bit SP FI DETEVMDPNDRANCNVPTUSRWBUPS
111
Default 0
Update rate Background read
7.10 T5/6 analog input 1 destination
Coding
Bit SP FI DE TE VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range Pr 0.00 to Pr 22.99
Default Pr 1.36
Update rate Read on drive reset
7.11 T7 analog input 2 mode
Coding
Bit SP FI DE TE VM DP ND RA NC NV PT US RW BU PS
1 111
Range 0 to 6
Default 6
Update rate Background read
Parameter value Parameter string Mode Comments
0 0-20 0 - 20 mA
1 20-0 20 - 0 mA
2 4-20.tr 4 - 20 mA with trip on loss Trip if I < 3 mA
3 20-4.tr 20 - 4 mA with trip on loss Trip if I < 3 mA
4 4-20 4 - 20 mA with no trip on loss
5 20-4 20 - 4 mA with no trip on loss
6 VOLt Voltage mode
7 th.SC Thermistor with short circuit detection
TH trip if R > 3 k 3
TH reset if R < 1 k 8
THS trip if R < 50 R
8 th Thermistor without short circuit detection
TH trip if R > 3 k 3
TH reset if R < 1 k 8
9 th diSp Thermistor display only with no trip
