See Pr 7.11 for a description
7.12 T7 analog input 2 scaling
Coding
BitSP FI DETEVMDPNDRANCNVPTUSRWBUPS
3111
Range 0.000 to 40.000
Default 1.000
Update rate Background read
7.13 T7 analog input 2 invert
Coding
BitSP FI DETEVMDPNDRANCNVPTUSRWBUPS
111
Default 0
Update rate Background read
7.14 T7 analog input 2 destination
Coding
BitSP FI DETEVMDPNDRANCNVPTUSRWBUPS
1 2 1111
Range Pr 0.00 to Pr 22.99
Default Pr 1.37
Update rate Read on drive reset
7.15
{in01, 0.81}
T8 analog input 3 mode
Coding
BitSP FI DETEVMDPNDRANCNVPTUSRWBUPS
1111
Range 0 to 9
Default Eur: 8, USA: 6
Update rate Background read
7.16 T8 analog input 3 scaling
Coding
BitSP FI DETEVMDPNDRANCNVPTUSRWBUPS
3 111
Range 0.000 to 40.000
Default 1.000
Update rate Background read
7.17 T8 analog input 3 invert
Coding
BitSP FI DETEVMDPNDRANCNVPTUSRWBUPS
111
Default 0
Update rate Background read
7.18 T8 analog input 3 destination
Coding
BitSP FI DETEVMDPNDRANCNVPTUSRWBUPS
1 2 1111
Range Pr 0.00 to Pr 22.99
Default Pr 0.00
Update rate Read on drive reset
