The following modes are available for the analog outputs.
If high-speed update mode is selected and the source for the output is one of the parameters designated for high-speed analog output operation (see
start of this section) the output is updated at a higher rate with special scaling. If the parameter selected is not designated for this mode the output is
updated at the normal rate. If speed feedback is selected for high-speed mode for both analog output 1 and analog output 2 the setting is ignored for
analog output 2. If the high-speed mode is selected the output is always a voltage signal.
7.19 T9 analog output 1 source
Coding
Bit SP FI DE TE VM DP ND RA NC NV PT US RW BU PS
21111
Range Pr 0.00 to Pr 22.99
Default Pr 3.02 = {di05, 0.40}
Update rate Read on drive reset
7.20 T9 analog output 1 scaling
Coding
Bit SP FI DE TE VM DP ND RA NC NV PT US RW BU PS
3 111
Range 0.000 to 40.000
Default 1.000
Update rate Background read
7.21 T9 analog output 1 mode
Coding
Bit SP FI DETEVMDPNDRANCNVPTUSRWBUPS
1 111
Range 0 to 3
Default 0
Update rate Background read
Parameter value Parameter string Mode
0 VOLt Voltage mode
1 0-20 0 - 20 mA
2 4-20 4 - 20 mA
3 H.Spd High speed up date mode
7.22 T10 analog output 2 source
Coding
BitSP FI DETEVMDPNDRANCNVPTUSRWBUPS
2 1111
Range Pr 0.00 to Pr 22.99
Default Pr 4.02
Update rate Read on drive reset
7.23 T10 analog output 2 scaling
Coding
Bit SP FI DE TE VM DP ND RA NC NV PT US RW BU PS
3111
Range 0.000 to 40.000
Default 1.000
Update rate Background read
