Menu 7
Parameter
structure
Keypad and
display
Parameter x.00
Parameter description
format
Advanced parameter
descriptions
Serial comms
protocol
Performance
114 Mentor MP Advanced User Guide
www.controltechniques.com Issue Number: 4
See Pr 7.21 description.
If an analog input is used with 4-20 mA or 20-4 mA current loop modes the respective bit (Pr 7.28 - analog input 2 and Pr 7.29 -analog input 3) is set
to one if the current falls below 3 mA. If the current is above 3 mA with these modes or another mode is selected the respective bit is set to zero.
An offset can be added to each analog input with a range from -100 % to 100 %. If the sum of the input and the offset exceeds ±100 % the results is
limited to ±100 %.
This parameter is an estimate of the SCR / thyristor junction temperature. If the value rises above 120
o
C, the drive will trip O.ht1.
7.24 T10 analog output 2 mode
Coding
BitSP FI DETEVMDPNDRANCNVPTUSRWBUPS
1111
Range 0 to 3
Default 0
Update rate Background read
7.28 T7 analog input current loop loss 2
7.29 T8 analog input current loop loss 3
Coding
Bit SP FI DE TE VM DP ND RA NC NV PT US RW BU PS
1111
Update rate Background write
7.30 T5/6 analog input 1 offset
Coding
Bit SP FI DE TE VM DP ND RA NC NV PT US RW BU PS
211
Range ±100.00 %
Default 0.00
Update rate Background read
7.31 T7 analog input 2 offset
7.32 T8 analog input 3 offset
Coding
Bit SPFI DETE VMDPND RANCNVPT USRWBUPS
111
Range ±100.0 %
Default 0.0
Update rate Background read
7.34 SCR / thyristor junction temperature
Coding
BitSP FI DETEVMDPNDRANCNVPTUSRWBUPS
111 1
Range
0 to 150
o
C
Update rate Background read
