Table 5-9 Serial communications look-up table
Trip Categories
Trips can be grouped into the following categories. It should be noted that a trip can only occur when the drive is not tripped or is already tripped but
with a trip with a lower priority number.
Unless otherwise stated, trips cannot be reset until 1.0 s after the trip has been accepted by the drive.
No. String No. String No. String
1
UV 92 UP ro 189 EnC1
2
t002 93 UP So 190 EnC2
3
AOC 94 UP ovr 191 EnC3
4
t004 95 UP OFL 192-196 t192 - t196
5
PS 96 UP uSEr 197 EnC9
6
Et 97 UP udf 198 EnC10
7
O.SPd 98 UP ACC 199 dESt
8
PS.10V 99 t099 200 SL1.HF
9
PS.24V 100 201 SL1.tO
10
t010 101 t101 202 SL1.Er
11
tunE1 102-111 t102 - t111 203 SL1.nF
12
tunE2 112-155 t112 - t155 204 SL1.dF
13
tunE3 156 SLAVE.Er 205 SL2.HF
14
tunE4 157 F. OVL 206 SL2.tO
15
tunE5 158 AOP 207 SL2.Er
16
tunE6 159 FbL 208 SL2.nF
17
tunE7 160 Fbr 209 SL2.dF
18
tunE 161 AtL.Err 210 SL3.HF
19
t019 162-167 t162 - t167 211 SL3.tO
20
It.AC 168 FdL 212 SL3.Er
21
O.ht1 169 FOC 213 SL3.nF
22
O.ht2 170 SL 214 SL3.dF
23
t023 171 S.OLd 215 SL.rtd
24
th 172 S.OV 216 t216
25
thS 173 th.Err 217-229 HF17 – HF29
26
O.Ld1 174 PLL Err
27 O.ht3 175 C.Prod
28
cL2 176 t176
29
cL3 177 C.Boot
30
SCL 178 C.BUSy
31
EEF 179 C.Chg
32-33
t032 - t033 180 C.Optn
34
Pad 181 C.RdO
35
CL.bit 182 C.Err
36
SAVE.Er 183 C.dat
37
PSAVE.Er 184 C.FULL
38-39
t038 - t039 185 C.Acc
40-89
t040 - t089 186 C.rtg
90
UP div0 187 C.Typ
91
UP Par 188 C.cpr
Priority Category Trips Comments
1 Hardware faults HF01 to HF16
These indicate fatal problems and cannot be reset. The drive is
inactive after one of these trips and the display shows HFxx
2 Non-resetable trips
HF17 to HF29, SL1.HF,
SL2.HF, SL3.HF
Cannot be reset
3 EEF trip EEF
Cannot be reset unless a code to load defaults is first entered in
Pr x.00
4 SMARTCARD trips
C.Boot, C.Busy, C.Chg,
C.Optn, C.RdO, C.Err, C.dat,
C.FULL, C.Acc, C.rtg, C.Typ,
C.cpr
SMARTCARD trips have priority 5 during power up
4 Encoder power supply trips Enc1, Enc3
These trips can only override the following priority 5 trips: Enc2, Enc9
or Enc10
5 Normal trips
All other trips not included in
this table
6 Self resetting trips UV
Under voltage trip cannot be reset by the user, but is automatically
reset by the drive when the supply voltage is within specification. Trip
not saved to EEProm
