Hardware fault trips
If this flag is set to one then the drive will trip (Et). If an external trip function is required, a digital input should be programmed to control this bit.
A zero to one change in this parameter will cause a drive reset. If a drive reset terminal is required on the drive the required terminal must be
programmed to control this bit.
See also Pr 10.35 overleaf
HF fault code Reason for trip
01 CPU address error
02 DMAC address error
03 Illegal instruction
04 Illegal slot instruction
05 Undefined exception
06 Reserved exception
07 Watchdog failure
08 Level 4 crash
09 Heap overflow
10 Router error
11 Access to the EEPROM failed or incorrect EEPROMs installed
12 Main program stack overflow
13 - 16 Not used
17 No comms from power processor
18 Bucket suppressor capacitor failure
19 Over heat on bucket suppressor or snubber circuits. Check internal fan operation
20 Power circuit - identification code error
21 Power processor - Watchdog failure
22 Power processor - Undefined exception
23 Power processor - Level overrun
24 Power processor - Spare
25 Power processor - Spare
26 Power processor - Spare
27 Power circuit thermistor 1 fault
28 Power software not compatible with user software
29 User processor - Armature timing error
10.32 External trip
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate Background read
10.33 Drive reset
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate Background read
10.34 No. of auto-reset attempts
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 5
Default 0
Update rate Background read
