Control Techniques Mentor MP User Manual

Parameter
structure
Keypad and
display
Parameter x.00
Parameter description
format
Advanced parameter
descriptions
Serial comms
protocol
Performance
Menu 10
Mentor MP Advanced User Guide 141
Issue Number: 4 www.controltechniques.com
If Pr 10.34 is set to zero then no auto reset attempts are made. Any other value will cause the drive to automatically reset following a trip for the
number of times programmed. Pr 10.35 defines the time between the trip and the auto reset. The reset count is only incremented when the trip is the
same as the previous trip, otherwise it is reset to 0. When the reset count reaches the programmed value, any further trip of the same value will not
cause an auto-reset. If there has been no trip for 5 minutes then the reset count is cleared. Auto reset will not occur on Et, EEF or HFxx trips. When a
manual reset occurs the auto reset counter is reset to zero.
If this parameter is 0 then Pr 10.01 (Drive OK is cleared every time the drive trips regardless of any auto-reset that may occur. When this parameter is
set the 'Drive OK' indication is not cleared on a trip if an auto-reset is going to occur.
When a value other than zero is written to the user trip parameter the actions described in the following table are performed. The drive immediately
writes the value back to zero. If the value is not included in the table a trip is initiated with the same trip number as the value provided the drive is not
already tripped.
The bits in this parameter correspond to the status bits in menu 10 as follows:
10.35 Auto-reset delay
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111
Range 0.0 to 25.0 s
Default 1.0
Update rate Background read
10.36 Hold drive OK until last attempt
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate Background read
10.38 User trip
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 255
Default 0
Update rate Background read
Action Values written to 10.38 Trip code
No action
1
31
200
205
210
217-245
UV
EEF
SL1.HF
SL2.HF
SL3.HF
HFx
Drive reset 100
Clear trip and trip time logs 255
10.40 Status word
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1
Range 0 to 32,767
Update rate Background write
15 14 13 12 11 10 9 8
Not used Not used Pr 10.14 Pr 10.13 Not used Not used Pr 10.10 Pr 10.09
76543210
Pr 10.08 Pr 10.07 Pr 10.06 Pr 10.05 Pr 10.04 Pr 10.03 Pr 10.02 Pr 10.01
