Control Techniques Mentor MP User Manual

Parameter
structure
Keypad and
display
Parameter x.00
Parameter description
format
Advanced parameter
descriptions
Serial comms
protocol
Performance
Menu 11
Mentor MP Advanced User Guide 157
Issue Number: 4 www.controltechniques.com
At some point, one of the Mentor 2 drives is replaced with a Mentor MP drive. The EIA (RS) -485 cable is wired to an SM-Applications module in slot
3 of the Mentor MP instead of being wired into the drive.
If the ANSI master device attempts to read Pr 2.06 (intending to read Mentor 2 Pr 2.06) the SM-Applications module will read Mentor MP Pr 2.06
giving an unexpected result to the ANSI master.
If Pr 11.59 on the Mentor MP is set to 3 (to enable Mentor 2 emulation for the installed SM-Applications Plus module) the SM-Applications Plus
module will treat incoming serial parameter reads for ANSI, ASCII and RTU modes as being in “Mentor 2” format.
In this example the SM-Applications module will receive the command to read Mentor 2 Pr 2.06 and will perform an equivalent parameter read (in this
case it will read Mentor MP Pr 2.25, divide the value by 100 and return the result).
In this way the master device does not need to be modified to consider a Mentor MP on the communications network. The SM-Applications Plus
documentation includes a list of the conversions provided.
Note that the SM-Applications Plus module does not provide a conversion for every Mentor 2 parameter
The user program in the SM-Applications Plus module, allows the user to create their own conversion functions if required, either to extend the set of
parameters which can be converted, or to override one of the conversions which are provided.
Only one Solutions Module on a Mentor MP may perform Mentor 2 parameter emulation at a time.
Intended for use by Solutions Modules.
This parameter defines the maximum on-time that the externally installed discharge resistor can stand volts without damage.
This parameter defines the time period which must elapse between consecutive capacitor discharge periods of maximum power as defined by
Pr 11.60. The setting of this parameter is used in determining the thermal filter of the external discharge resistor installed. It is assumed that the
temperature will fall by 99 % in this time, and so the filter is Pr 11.60 / 5. If either Pr 11.60 or Pr 11.61 are set to their default values, the software
assumes that only the internal discharge resistance is being used.
The external discharge resistor temperature is modelled by the drive as shown below and displayed as a percentage in Pr 11.63. The temperature
rises in proportion to the power flowing into the resistor and falls in proportion to the difference between the resistor temperature and ambient. The
same model is used to determine the temperature of the internal discharge resistors.
Value
0 No Solutions Module will operate communications in porting mode.
1 Solutions Module in slot 1 will operate communications in porting mode if capable.
2 Solutions Module in slot 2 will operate communications in porting mode if capable.
3 Solutions Module in slot 3 will operate communications in porting mode if capable.
11.60 & 11.61 Application parameters
Coding
BitSPFIDETEVMDPNDRANCNVPTUSRWBUPS
11 1
Range ±16,000
Update rate Background
11.62 Full power discharge time
Coding
BitSPFIDETEVMDPNDRANCNVPTUSRWBUPS
1 111
Range 0 to 25.0 s
Default 0.0
Update rate Background read
Drive voltage rating Switching point volts
480 V 1100 V
575 V 1400 V
690 V 1600 V
11.63 Full power discharge period
Coding
BitSPFIDETEVMDPNDRANCNVPTUSRWBUPS
1 111
Range 0 to 1500.0 s
Default 0.0
Update rate Background read
