Control Techniques Mentor MP User Manual

Menu 11
Parameter
structure
Keypad and
display
Parameter x.00
Parameter description
format
Advanced parameter
descriptions
Serial comms
protocol
Performance
156 Mentor MP Advanced User Guide
www.controltechniques.com Issue Number: 4
The power PCB software version consists of two numbers xx.yy. xx.yy is displayed in this parameter. Where xx specifies a change that affects
hardware compatibility, yy specifies a change that affects product documentation.
Defines an output parameter or input parameter when input or output serial mode is selected by serial mode parameter in the application menu.
Intended for use by Solutions Modules.
Scales the input data in input serial mode. Intended for use by Solutions Modules.
This parameter allows the EIA (RS) -485 communications port of the specified Solutions Module slot to emulate an MD29 or Mentor 2.
The module in the specified slot will if capable, perform parameter mappings and conversions so that the module “looks like” an MD29 or Mentor 2.
For example :
An ANSI master device transmits a parameter read message to a number of Mentor 2 drives over EIA (RS) -485.
53
2D
480 V
Four
1200 A MP1200R
54 1850 A MP1850R
55
690 V
1200 A MP1200R
56 1850 A MP1850R
57
2A
575 V
Two
350 A MP350A5
58 470 A MP470A5
59
Four
350 A MP350A5R
60 470 A MP470A5R
61
2B
Two
700 A MP700A5
62 825 A MP825A5
63
Four
700 A MP700A5R
64 825 A MP825A5R
65
2C Two
1200 A MP1200A5
66 1850 A MP1850A5
67
2D Four
1200 A MP1200A5R
68 1850 A MP1850A5R
11.56 Power PCB software version
Coding
BitSPFIDETEVMDPNDRANCNVPTUSRWBUPS
21 1 1 1
Range 1.00 to 99.99
Update rate Write at power-up
11.57 Serial programmable source
Coding
BitSPFIDETEVMDPNDRANCNVPTUSRWBUPS
1 2 1111
Range Pr 0.00 to Pr 22.99
Default 00.00
Update rate Background
11.58 Serial scaling
Coding
BitSPFIDETEVMDPNDRANCNVPTUSRWBUPS
111
Range 0 to 1999
Default 1000
Update rate Background
11.59 Mentor 2 parameter emulator module control
Coding
BitSPFIDETEVMDPNDRANCNVPTUSRWBUPS
111
Range 0 to 3
Default 0
Update rate Background
Number Frame Voltage rating Quadrant variant Current rating Model
