Mentor MP Advanced User Guide 155
Issue Number: 4 www.controltechniques.com
11.55 Drive rating number
Coding
BitSPFIDETEVMDPNDRANCNVPTUSRWBUPS
111
Range 0 to 68
Update rate Background read
Number Frame Voltage rating Quadrant variant Current rating Model
1
1A
480 V
Single
25 A MP25
2 45 A MP45
3 75 A MP75
4
Four
25 A MP25R
5 45 A MP45R
6 75 A MP75R
7
1B
Single
105 A MP105
8 155 A MP155
9 210 A MP210
10
Four
105 A MP105R
11 155 A MP155R
12 210 A MP210R
13
1A
575 V
Single
25 A MP25
14 45 A MP45
15 75 A MP75
16
Four
25 A MP25R
17 45 A MP45R
18 75 A MP75R
19
1B
Single
105 A MP105
20 155 A MP155
21 210 A MP210
22
Four
105 A MP105R
23 155 A MP155R
24 210 A MP210R
25
2A
480 V
Single
350 A MP350
26 420 A MP420
27 550 A MP550
28
Four
350 A MP350R
29 420 A MP420R
30 550 A MP550R
31 690V Single 350 A MP350
32
33 2A 690 V Single 470 A MP470
34 2A 690 V Four 350 A MP350R
35
36 2A 690 V Four 470 A MP470R
37
2B 480 V
Single
700 A MP700
39 900 A MP900
40 Four 700 A MP700R
41
42
2B
480 V Four 900 A MP900R
43
690 V Single
700 A MP700
44 825 A MP825
45
46
2B 690 V Four
700 A MP700R
47 825 A MP825R
48
49
2C
480 V
Single
1200 A MP1200
50 1850 A MP1850
51
690 V
1200 A MP1200
52 1850 A MP1850
