Menu 11
Parameter
structure
Keypad and
display
Parameter x.00
Parameter description
format
Advanced parameter
descriptions
Serial comms
protocol
Performance
154 Mentor MP Advanced User Guide
www.controltechniques.com Issue Number: 4
The Drive Onboard Application Lite Ladder Programming Events parameter holds the number of times a Onboard Application Lite Ladder program
download has taken place and is 0 on dispatch from the factory. If the Drive Onboard Application Lite Ladder Programming Events is greater than the
maximum value which may be represented by this parameter the value will be clipped to the maximum value. This parameter is not altered when
defaults are loaded.
The Onboard Application Lite Ladder Program Maximum Scan Time parameter gives the longest scan time within the last ten scans of the drive
Onboard Application Lite Ladder Program. If the scan time is greater than the maximum value that may be represented by this parameter the value
will be clipped to the maximum value.
The Drive Onboard Application Lite Ladder Program first run parameter is set for the duration of the first ladder diagram scan from the ladder diagram
stopped state. This enables the user to perform any required initialization every time the ladder diagram is run. This parameter is set every time the
ladder is stopped.
Pr 11.52 and Pr 11.53 give a unique drive serial number for the drive.
Digits 876 543 210
Format
Value Description
-n
Onboard Application Lite Ladder Program caused a drive trip due to an error condition while
running rung n. Note that the rung number is shown on the display as a negative number.
0 Onboard Application Lite Ladder Program is not installed.
1 Onboard Application Lite Ladder Program is installed but stopped.
2 Onboard Application Lite Ladder Program is installed and running.
11.49 Drive Onboard application lite ladder programming events
Coding
BitSPFIDETEVMDPNDRANCNVPTUSRWBUPS
111 11
Range 0 to 65,535
Update rate Background write
11.50 Drive Onboard Application Lite Ladder Program Average Scan Time
Coding
BitSPFIDETEVMDPNDRANCNVPTUSRWBUPS
111 1
Range 0 to 65,535 ms
Update rate Onboard Application Lite Ladder program execution period
11.51 Drive Onboard Application Lite Ladder Program first run
Coding
BitSPFIDETEVMDPNDRANCNVPTUSRWBUPS
1111
Range 0 or 1
Update rate Onboard Application Lite Ladder program execution period
11.52 Drive serial number
Coding
BitSPFIDETEVMDPNDRANCNVPTUSRWBUPS
11 1
Range 0 to 999 999 999
Update rate Background read
11.53 Build location
Coding
BitSPFIDETEVMDPNDRANCNVPTUSRWBUPS
11 1
Range 0 to 255
Update rate Background read
Parameter Digits Description Range
11.53 All Build location 0-255
11.52 8-3 Works order number 0-999999
11.52 2-0 Number 0-999
