Menu 4
Mentor MP Advanced User Guide 61
Issue Number: 4 www.controltechniques.com
The motoring current limit applies in either direction of rotation when the machine is producing motoring torque. Similarly the regen current limit
applies in either direction when the machine is producing regenerating torque. The symmetrical current limit can override either motoring or
regenerating current limit if it is set at a lower value than either limit.
The torque offset is updated every 4 ms when connected to an analog input, and so Pr 4.08 should be used for fast updating if required.
The torque offset is added to the torque reference when Pr 4.10 is one. The torque offset is updated every 4 ms when connected to an analog input,
and so Pr 4.08 should be used for fast updating if required.
The value of this parameter refers to switches TM0 to TM4 on Menu 4 diagram.
When this parameter is set to 1, 2 or 3 the ramps are not active while the drive is in the run state. When the drive is taken out of the run state, but not
disabled, the appropriate stopping mode is used. It is recommended that coast stopping or stopping without ramps are used. However, if ramp stop
mode is used the ramp output is pre-loaded with the actual speed at the changeover point to avoid unwanted jumps in the speed reference.
0: Speed control mode
The torque demand is equal to the speed loop output.
1: Torque control
The torque demand is given by the sum of the torque reference and the torque offset, if enabled. The speed is not limited in any way, however, the
drive will trip at the overspeed threshold if runaway occurs. When ‘RUN FWD / RUN REV’ is removed while in ‘Torque mode’, the drive will stop
in the method selected by Pr 6.01.
4.07 Symmetrical current limit
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 1 111
Range 0 to MOTOR1_CURRENT_LIMIT_MAX %
Default 150.0
Second motor
parameter
Pr 21.29
Update rate Background read
4.08 Torque reference
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
12 11
Range ±USER_CURRENT_MAX %
Default 0.00
Update rate 4 ms read
4.09 Torque offset
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 11
Range ±USER_CURRENT_MAX %
Default 0.0
Update rate 4 ms read
4.10 Torque offset select
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate 4 ms read
4.11 Torque mode selector
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 4
Default 0
Update rate 4 ms read
