Control Techniques Mentor MP User Manual

Menu 5
Parameter
structure
Keypad and
display
Parameter x.00
Parameter
description format
Advanced parameter
descriptions
Serial comms
protocol
Performance
74 Mentor MP Advanced User Guide
www.controltechniques.com Issue Number: 4
The rated speed defines the base speed of the motor. It is also used for:
1. The calculation of 'estimated speed'.
2. Used by the rotating autotune function to determine the speed levels for measuring the field saturation breakpoints.
3. Used to determine the speed used in the auto tuning inertia test (see Pr 5.12 {SE13, 0.34}).
This parameter is set to 165.0° at power-up.
A value of 165° corresponds to the fully phased back condition and therefore zero output voltage.
When enabled, the firing angle Pr 5.01 is controlled by Pr 5.10. This mode is valuable for system diagnosis, particularly where instability is present,
since it allows the drive to operate without the influence of either the speed loop or the current loop, thereby eliminating their effect upon the system.
5.08
{SE08, 0.29}
Base speed
Coding
Bit SP FI DETEVMDPNDRANCNVPTUSRWBUPS
1111
Range 0.0 to 10,000.0 rpm
Default 1000
Second motor
parameter
Pr 21.06
Update rate Background read
5.09
{SE06, 0.27}
Armature rated voltage
Coding
BitSP FI DETEVMDPNDRANCNVPTUSRWBUPS
11 111
Range 0 to ARMATURE_VOLTAGE_MAX Vdc
Default
For 480 V Drive: Eur: 440, USA 500
For 575 V Drive: Eur: 630, USA 630
For 690 V Drive: Eur: 760, USA 760
Second motor
parameter
Pr 21.09
Update rate Background read
5.10 Direct firing angle
Coding
Bit SP FI DE TE VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 165.0°
Default 165.0
Update rate 6 times mains frequency
A value of 0 in the firing angle Pr 5.10 corresponds to fully
phased forward and therefore maximum output voltage.
5.11 Direct firing angle enable
Coding
Bit SP FI DETEVMDPNDRANCNVPTUSRWBUPS
111
Default 0
Update rate Background read
This parameter must be used with caution. When the firing
angle is controlled directly by Pr 5.10 there is no protection
against excessive acceleration, output voltage or current
other than the instantaneous over current trip. Also take care
to reset Pr 5.11 to 0 after the completion of tests.
WARNING
WARNING
